BP 115 (45 ”)
| MODEL | BP 115 |
|---|---|
| Cutting Table Width | 45 " / 1150 mm |
| Feed Height | 6.5 " / 165 mm |
| Useful Rear Table Length | 45 " / 1150 mm |
| Stainless Steel Air Side Tables | 24.4 " x 32.3 " / 620 mm x 820 mm and transfer corners |
| Minimum Cut without False Clamp | 0.8 " / 20 mm |
| Minimum Cut with False Clamp | 3 " / 77 mm |
| Clamping force | 560 - 10115 lb / 2.5 - 45 kN |
STANDARD FEATURES
Powerful gear drive for the knife
Gear box with helical spur gears with a 10-year warranty
Digital servo drive positioning system for the backgauge
Hydraulic clamp
Stainless steel plated and slot-less cutting table
Cutting table and side tables with air bed
TS computer with 18.5 ” high resolution color touch screen
CIP3 / CIP4 enabled
LED table light and cut line indicator
Built-in knife hoist with setting gauges and knife guard
Self-monitoring safety light barrier
Two-hand cut control
Complete rear table guarding
Overload protection device
Ejector for cutting stick
Tool cabinet
AVAILABLE OPTIONS
Enlarged air side tables
Carbide tipped blades
Lift kit for taller working height
Automatic Waste Removal System AWR
Multi nozzle blow down device for AWR-system
Front hold-down device for knife
Smart clamp (limited clamping stroke)
Low pressure device (for corrugated and pressure sensitive material)
Motorized knife adjustment
Barcode scanner
S2C package (Straight To Cut), with bar code scanner and CIP3/4 network connectivity
Swivel backgauge
Swivel-tilt backgauge
Print mark positioner
Built-in knife cleaning device (for glued products)
Variable knife speed
Rear loading options (retractable side guides and others)
